Handrails & Guardrails
Coordinated railing systems with complete connection and fabrication detail.
What we do
Detail in every deliverable.
Railings are detailed around the actual stair, slab, and edge conditions. We lay out post spacing, rail heights, transitions, returns, infill, and attachment details, then provide fabrication views that make joints and terminations clear. A coordinated package helps avoid mismatched rails at landings and last-minute changes in the field.
Typical deliverables
How it comes together
Methods, tools & applications.
Detailing techniques
- Set out post positions against stair pitch and landing geometry
- Resolve continuous rail transitions, end returns, and wall clearances
- Detail base plates, welds, splice locations, and mounting conditions
Tools & equipment
3D layouts and CAD shop drawings; tube cutting, bending, drilling, and welding information is shown as applicable to the approved rail design.
Typical applications
Pipe and tube rails, picket guards, industrial safety rails, and architectural handrails with finishes and profiles defined by project specifications.
